Spinlock XTR Clutch

• XTR Mk2 featuring new handle and cassette for improved feel and power
• Superb mid load holding performance
• Unique Reactor Cam technology - linked base and cam react together in one self contained module
• ‘Reactive Clutching’ - line holding is consistent and fast across the full diameter range - release is smooth and progressive for maximum control
• Significant rope holding improvement on the latest small diameter rope types
• Ultra lightweight alloy/composite construction
• New handle offer improved feel and confidence in operation
• Improved mechanism geometry boosts clutching power and reduces 'take up'
• Reactor cam module is easily removed, for on deck cleaning and servicing
• Single units only
• Side mount versions available
• One person installation either top mounted or through bolted
• Available in Black, Silver, White, Blue, Green, Orange and Yellow

Specification:

XTR0812

Lines 8-12mm (5/16'-1/2')

Loads upto 1000kgs (2200lbs)

Side Mounting

Side mounting is usually the neatest solution for spars, side decks and coamings

Weights and Fasteners:

Weights

XTR Single - 340g (12oz)

Fasteners

XTR Single - 2 x M8 (5/16") HEX Head (not supplied)

Load Graph:
